::heading=Context
The Configurator is presenting the Palletizing Solution in a 3D environment. Depending on the simulation, you might be interested in adjusting the default camera view and zoom in or out.
::heading=Video demo (1:05)
Link: https://drive.google.com/file/d/151yNHMduUX_2GqqXS2HCVm998sO9BLMu/view?usp=sharing
::heading=Mouse actions
The camera view and 3D scene can easily be controlled by using the following mouse buttons:
| Action | What it does |
| The camera view will change as the mouse cursor is moved allowing one to look at the end-of-line palletizing cell from different angles. | |
| The camera angle will remain the same while giving the impression that you are moving the palletizing cell across the floor as you drag the mouse cursor. | |
| Rolling the mouse scroller forward and backwards will zoom in and out accordingly. |
::heading=Resetting the camera view
The camera view will reset to the default position anytime one of the process steps (box, pallet, conveyor and/or pattern) has been opened and closed.
